Cone Crusher

Cone crushers are suitable for crushing various ores and rocks of medium to high hardness. They feature reliable structure, high production efficiency, convenient adjustment, and economical operation. Their spring safety system acts as an overload protection device, allowing foreign objects like iron blocks to pass through the crushing chamber without damaging the machine. A dual-seal system, using either dry oil or water, isolates stone powder from the wetted mixture, ensuring reliable operation. The crushing chamber design is determined by the intended use of the ore; the standard type is suitable for medium crushing, the medium-sized type for fine crushing, and the short-head type for fine crushing.

When the cone crusher is working, the motor's rotation, via a pulley or coupling, causes the drive shaft and cone to oscillate around a fixed point under the influence of the eccentric sleeve. This causes the crushing wall of the cone crusher to alternately approach and move away from the surface of the crushing wall on the adjusting sleeve, subjecting the ore to continuous impact, compression, and bending within the crushing chamber, thus achieving ore crushing.

contact us
  • Cone Crusher

Key Features

Open-circuit capacity (t/h)

Model Max. feed size (mm) Min. discharge size (mm) Motor power (KW) Closed-side discharge opening (mm)
Output (tonnes per hour)
6 10   13   16   19   22   25   38   51   64
XHKJC 1000 160 13 90~110 80 100 135 150 175 235
XHKJF 1000 115 10 90~110 65 75 90 120 135 150
XHKJS 1000 80 8 90~110 50 55 65 70 95
XHKJC 1200 180 13 110~132 115 135 150 180 200 260
XHKJF 1200 130 10 110~132 100 110 120 135 165 175
XHKJS 1200 90 10 110~132 80 105 110 140
XHKJC 1300 200 16 132~160 150 180 200 230 310 390
XHKJF 1300 150 13 132~160 115 140 160 190 210
XHKJS 1300 102 10 132~160 90 115 145 160
XHKJC 1400 215 19 185~220 200 220 260 330 420
XHKJF 1400 160 16 185~220 155 180 200 220
XHKJS 1400 115 13 185~220 150 190 210 230
XHKJC 1500 235 22 185~220 240 265 300 400 510 570
XHKJF 1500 175 19 185~220 215 240 265 320
XHKJS 1500 130 13 185~220 180 210 235 255 275
XHKJC 1700 267 22 250~300 330 390 525 655 725
XHKJF 1700 203 16 250~300 230 270 300 330
XHKJS 1700 140 13 250~300 185 225 265 340

Closed-circuit production capacity (t/h)

Model Max. feed size (mm) Min. discharge size (mm) Motor power (KW) Closed-side discharge opening (mm)
Output (tonnes per hour)
6    10   13   16   19   22   25   38   51   64
XHKJC 1000 160 13 90~110 70 90 125 135 160 215
XHKJF 1000 115 10 90~110 55 65 70 90 120 135
XHKJS 1000 80 8 90~110 47 50 60 67 90
XHKJC 1200 180 13 110~132 105 120 135 160 180 220
XHKJF 1200 130 10 110~132 72 92 105 135 150 170
XHKJS 1200 90 10 110~132 70 90 100 125
XHKJC 1300 200 16 132~160 135 160 180 200 290 350
XHKJF 1300 150 13 132~160 105 125 135 160 180
XHKJS 1300 102 10 132~160 80 105 135 140
XHKJC 1400 215 19 185~220 180 200 230 310 400
XHKJF 1400 160 16 185~220 130 160 180 200
XHKJS 1400 115 13 185~220 135 170 190 210
XHKJC 1500 235 22 185~220 210 245 290 380 480 530
XHKJF 1500 175 19 185~220 195 235 250 295
XHKJS 1500 130 13 185~220 170 190 220 230 250
XHKJC 1700 267 22 250~300 300 350 475 600 660
XHKJF 1700 203 16 250~300 210 250 280 300
XHKJS 1700 140 13 250~300 170 205 240 310
